the use of color lead balance type, dual-axis balance type or rigid suspension, the mass balance block is installed between the front and rear steel bar spring, which can make the wind of the front and rear leaf spring equal to change, so that the front and rear axis force balance.
2. carbon dioxide gas inverter welding, the whole frame by shot blasting treatment, make the vehicle more beautiful. The longitudinal beam telescopic low plate, the net drawing length can reach 315 meters, which solves the problem of difficult transportation of large and ultra-long items.
| Name | 2 Axle Low Flat Bed Semi Trailer |
| Size | 12500*3000*1100 (mm) |
| Payload | 40000KG |
| Main beam | Heavy duty I beam |
| Side beam | 250mm I beam |
| Plate | 4mm checked plate |
| Ladder | Mechanical spring ladder or hydraulic ladder |
| Axles | 2 * 13ton capacity (Brand optional) |
| Suspension | Mechanical suspension (Air suspension optional) |
| Leaf spring | 10pcs |
| Tire | 12R22.5 / 11.00R20 8pcs (Other size optional) |
| Rim | 9.00-22.5 / 11.00R20 8pcs (Other size optional) |
| King pin | 2’’/3.5’’ bolt type |
| Landing gear | 28 Ton two speed |
| Braking system | Double air chamber ,brake valve,45L air tanks ;ABS optional |
| Electrical | LED light , 7 ways ,24V |
Feature
▪ The main beam is made of HG high-strength steel, which has strong bearing capacity.
▪The side beam adopts "H" steel, and the durable design avoids the deformation of the side beam.
▪The loading ramp is made of high-strength steel, which has a high bearing capacity and will not deform when handling heavy
equipment.
▪Polyurethane paint, long service life, avoiding rusting of the vehicle.
▪Spare parts from world famous brands to ensure high quality and save cost.
