Product Details
1. the suspension adopts non-independent steel plate stamping rigid suspension (optional air suspension) composed of tandem leaf spring and suspension support, reasonable structure, with strong stiffness and strength, used to support the load to slow the impact.
2. semi-trailer accessories are made of well-known manufacturers at home and abroad, and in strict accordance with the quality system document requirements to purchase, inspection, use to ensure the good performance of the vehicle.
| Dimension | 12500*2500*3200mm ( can be customized ) |
| Loading | 20T,30T, 40T, 45T, 50T, 60T |
| Tire | 11.00R20, 12.00R20,12R22.5, 385/65R22.5 Triangle/Hankook/ Bridgestone brand |
| Material | Main beams Q345B, upper flange:14mm, middle:8mm, down:16mm ( can be customized ) |
| Axles | 13T/16/20T BPW or FUWA brand |
| King Pin | 2 inch or 3.5 inch JOST Brand |
| Brake System | WABCO Valve with big chamber |
| Landing Gears | JOST brand two-speed, Manual operating heavy duty 28ton |
| JOST brand two-speed, Manual operating heavy duty 28ton | Bogie suspension, spring suspension, Air suspension |
| Floor | 3mm,4mm,6mm diamond steel plate |
| Sidewall height | 300mm 600mm 800mm 1200mm 2000mm by needs |
| Other parts | 1 tool boxs, 1 spare tire carrier |
Multi Support parts:
12 sets container locks for carrying 1 unit 40ft, 45ft container and 2 units 20ft container.
Rope and hooks help yo fasten cargo, suitable for multi cargo transporting.
Automatic welding :
support vehicle longer time working without repairing.
Quality Axles suspensions and Brake system：
BPW, FUWA worldwide best axles work with WABCO brake valve, more effectively brake for safe and save tire cost.
